Thin sections, impregnated with blue epoxy to highlight pore space, provide information on texture (grain size, sorting) grain composition, intergranular phases and pore types.  Modal analysis data (point count) quantifies each of the rock and pore space components as a percentage of the rock volume.

reflected light 1.jpg (125044 bytes)    reflected light 3.jpg (112190 bytes)    reflected light 2.jpg (126650 bytes)

Fluorescent light microscopy uses an auto-fluorescing epoxy to help identify pore space not large enough to be visible during standard thin section evaluation.  This "microporosity" can be present in altered grins, intergranular clay and very small remnants of intergranular pores.



Reflected light photomicrograph taken at 20x showing drill cuttings from a high permeability, arkosic gas sand.  Photomicrographs like this can be used to compare rock from other zones or wells.
